Description
Part Number
5902037
Engine Brand
Vanguard® 810 EFI with Oil Guard™
Engine Power Rating (HP) *
28
Displacement (cc)
810
PTO
Electric
Cylinders
2
Starter
Electric
Fuel Tank Capacity (litres)
30
Cutting Width in(cm)
52 (132)
Cutting Height in(cm)
1.75 – 5 (44 – 127)
Spindles
Aluminium greaseable
Deck Construction
iCD™ Cutting System
Suspension
Adjustable coil-over-shock; Operator Suspension Platform
Transmission
Hydro-Gear® ZT-3800™ transaxles with 7″ cooling fans & external oil coolers
Drive Axles (in)
1.125
Caster Tyres (in)
13 x 5 – 6, Flat-free
Drive Tyres (in)
23 x 10.5 – 12
Ground Speed-Fwd (kph)
0 – 16.1
Ground Speed-Rev (kph)
0 – 8.1
Overall Length (mm)
1702
Overall Width (mm) Deflector Down / Up
1651 / 1391
Dry Weight (kg)
426
Seat Package
Not Available
Instrumentation
Fuel gauge, hour meter
ROPS
Not Available
Controls / Safety Group
Operator presence in platform, parking brake safety circuit for starting engine, automatic PTO restart
Parking Brake / Safety Circuit
Hand-operated internal transaxle brake
Warranty (Engine) †
3-Year limited manufacturer’s warranty
Warranty (Balance of Machine) †
4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see operator’s manual for complete details.
