Description
Part Number
5901918
Engine Brand
Briggs & Stratton® Commercial Series
Engine Power Rating (HP) *
27
Displacement (cc)
810
PTO
Electric
Cylinders
2
Starter
Electric
Fuel Tank Capacity (litres)
20.8
Cutting Width in(cm)
52 (132)
Cutting Height in(cm)
1.5 – 5 (38 – 127)
Spindles
Aluminium greaseable
Deck Construction
iCD™ Cutting System
Suspension
Adjustable front and rear coil-over-shocks with pivoting front axle and a rear swing-arm with large adjustable coil-over-shocks
Transmission
Dual commercial Hydro-Gear® Integrated ZT-3200® transaxles with 7″ cooling fans
Drive Axles (in)
1.125
Caster Tyres (in)
13 x 6.5 – 6
Drive Tyres (in)
22 x 11 – 10
Ground Speed-Fwd (kph)
0 – 16.1
Ground Speed-Rev (kph)
0 – 8.1
Overall Length (mm)
2058
Overall Width (mm) Deflector Down / Up
1696 / 1436
Dry Weight (kg)
481
Seat Package
Mid back adjustable suspension seat with armrests
Instrumentation
Dual-function hour meter, fuel level gauge in tank
ROPS
180° foldable
Controls / Safety Group
Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit/adjustable twin steering controls
Parking Brake / Safety Circuit
Hand-operated internal transaxle brake
Warranty (Engine) †
3-Year limited manufacturer’s warranty
Warranty (Balance of Machine) †
4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see operator’s manual for complete details.
