Description
Welcome to superior battery technology from FusionCore. The EV's four swappable batteries deliver the all-day, reliable high-performance power you need in a commercial mower. No pullies, belts, engine oil changes, or driving vibrations. They've been replaced with the quiet hum of success. Powered by FusionCore – the industry’s first swappable lithium-ion battery system.
Features
- FusionCore QuikSwap batteries.
- X3 Constant drive spindles are designed to prevent motor damage by absorbing blade impact, protecting the machine from these unavoidable, accidental run-ins with ordinary obstacles.
- Spindles are easily serviceable, allowing you to rebuild and not replace.
- Next-Gen wheel drives – Commercial durability and comfort reign supreme. Transaxles are driven with a brushless electric drive motor coupled with a planetary gearbox that increases torque. Your ride will feel the same as a gas-powered machine…minus the vi
- Suspension seat is adjustable and has the new addition of a low-profile seat mechanism for added comfort.
- Failsafe breaking – the failsafe braking design automatically applies the brake system when the operator is not present, or should a fault occur in the system. It’s stopping power when you need it and even when you think you don’t.
- An automotive-style tubular frame, it’s unique to the mowing industry and increases durability by withstanding force from any direction. This high-strength, premium frame is positioned with a lower centre of gravity to improve stability while mowing on h
- Cut selection Offers 15 cutting positions, ranging from 38.1 mm – 127 mm, to make your lawn look its best.
- Foot-Operated deck lift.
- X-FACTOR® 3 deck. The deck has been completely redesigned for better grass dispersion. Its new look is constructed from 7-gauge steel to deliver years of solid performance.
- Productivity – 6.6 acres per hour.
Technical specifications
Warranty Information
| Domestic Warranty | 5 Year / 1500 Hour Domestic Warranty |
|---|---|
| Commercial Warranty | 5 Year / 1500 Hour Commercial Warranty |
| Hire/Rental Warranty | 90 Day Hire / Rental Warranty |
Miscellaneous
| Blade(s) | 3 x Bar blades |
|---|---|
| Number of Batteries | 4 |
| Battery Type | Li-ion |
| Battery Size | Fusion Core 4KW |
Battery Specs
| Voltage | 56v |
|---|---|
| Charge Time | 12 hours |
| Battery Capacity | 16 kkw/h |
Dimension Specs
| Dry Weight | 595 kg |
|---|---|
| Height | ROPS up 1193 mm, ROPS down 1244 mm |
| Width | 1600 mm with chute up |
| Overall Length | 2108 mm |
Zero Turn Mower Specs
| Ground Speed – Forward | Up To 17.7 km/h |
|---|---|
| Brakes | Hand brake electric parking |
| Seat | High back comfort with suspension and armrests |
| Construction | Frame 1" x 3" STEEL Tubular frame welded |
| ROPS | Folded ROPS standard |
| Cup Holder | Yes |
| Deck System | X-Factor 3® Fabricated |
| Deck Lift | Foot-operated |
| Deck Construction | Fabricated 7 Gauge |
| Spindles | Electric |
| Discharge Chute | High density, rubberised |
| Steering | Twin-lever steering provides independent control of each drive wheel. Speed, forward, reverse, and turns are all controlled with hand-operated controls |
Engine and Fuel Specs
| Engine | FusionCore Lithium Battery |
|---|---|
| Type | Li-ion |
| Fuel Capacity | Electric |
Safety Features
| Safety Features | Operator presence system connected to seat, and park brakes |
|---|
Hydrostatic Drive System Specs
| Hydrostatic Drive System | Electric Wheel drive |
|---|---|
| Transmission | Gravely gearbox |
Cutting Dimensions
| Cutting Widths | 60" (1524 mm) Side discharge. |
|---|---|
| Cutting Height(s) | 38 mm – 127 mm |
