Description
Feature | Specifications |
---|---|
Engine | Kawasaki® FX801V |
Horsepower | 25.5 |
Cylinders | 2 |
Oil Capacity | 2.0L |
Drive System | Hydro-Gear® 12cc Pumps & Parker Wheel Motors |
Hydro Oil Cooler | Standard |
Fuel Capacity | 26 Litre |
Steering Control | Joystick, Twin Lever |
Stand-up Deck | Standard |
Pivoting Front Axle | Standard |
Roll-Over Protection | Standard |
Tires, Rear | 24×12-12 |
Tires, Front | 13×6.5-6 |
Turning Radius | Zero-Turn |
Ground Speed | 17kmh |
Length | 84″ |
Height : top of seat back | 48″ |
Height : top of ROPS extended | 72″ |
Height : top of ROPS folded | 55″ |
Width, Tractor (outside rear tires) | 51″ |
Width, Deck w/ Chute | 65″, 73″ |
Width, Deck Chute Up | 53″, 61″ |
Cutting Width | 52″, 60″ |
Cutting Height | 2″ – 5″ (1/4″ increments) |
Deck Construction | Laminated Welded 10 Gauge Steel Deck with 10 Gauge Strategic Reinforcements, including protective bullnose front & high impact anti-scalp rollers; 3/8″ x 2″ wear bar on trim edge |
Deck Engagement | Electric, Warner® |
Blade Length | 18.375″, 21″ |
Spindle Assembly | Cast iron housing; 1.4″ diameter shaft; maintenance free & field serviceable |
Blade Tip Speed, approx. | 19,000 fpm |
Weight | 1081 lbs, 1106 lbs, 1096 lbs |
Seat | Deep Bolstered, Maximum Comfort seat with static suspension, adjustable slides, and seat belt |
Other Standard Features | Hour Meter, Electric Start, Arm Rest, Cup Holder, Front Step |
